SPCAD FOR CADMATE
It enables seamless importing of various file formats such as KML, Shapefile, CSV, GPX, and more. Similarly, users can effortlessly export drawings to formats like KML, Shapefile, GeoJSON, and CSV. Users can easily manage coordinate systems in their drawings. They can assign/unassign coordinate systems, display system information, and convert coordinate values for different projections.
Key Features- Topography: SPCAD offers robust tools for topographic analysis, including defining alignments, creating TIN surfaces, contour lines, and elevating points on TIN.
- Cadaster: SPCAD simplifies parcel tasks with its Parcel Manager, allowing users to create, add, locate, label, and organize parcels. Lot subdivision methods and parcel creation from polylines further enhance its capabilities.
- Geometry: Users can expedite geometry-related tasks with SPCAD, including creating right-angled triangles, rectangles, and angle bisectors. The add-on also facilitates converting 2D to 3D polylines and reducing polyline nodes.
START YOUR 14 DAYS FREE TRIAL TODAY!
Start your 14-day fully functional trial of SPCAD for CADMATE today and revolutionize your CAD experience. For more information on installation, visit our help page.
What’s new in SPCAD V24.1?
Display cursor coordinates in a panel and track multiple coordinate systems.
Georeference raster images directly within the CAD workspace.
Generate Thiessen polygons around points for area of influence analysis.
Generate quick contours over terrain points for better terrain visualization.
Import DEM as points, TIN, or contours in CAD format.
Export triangulated surfaces as DEM raster files for external use.
Measure the distance between points with just a few cursor clicks.
Import LandXML files into your CAD environment for smooth integration.
Export features from your CAD drawings into the LandXML format efficiently.
Convert intersecting lines into polygons automatically in your drawing.
Quickly label line segments with both length and bearing information.
Easily mark front yard boundaries using parallel lot partitioning.
